Description
Great Oak Curated Industrial Equipment:
Part of our industrial collection, selected for durability and performance.
Features & Details
- 50-Inch Bending Capacity: This sheet metal brake is designed to bend metal sheets up to 50 in wide with bending angles ranging from 0° to 135°. Perfect for large custom fabrication projects.
- Versatile Material Compatibility: Supports mild steel, stainless steel, copper, and aluminum.
- Capable of bending 16 gauge (1.5 mm) mild steel sheets with ease.
- Modular Bending Dies: Equipped with 16 segment fingers (2" x 4 pcs, 3" x 6 pcs, 4" x 6 pcs) that can be freely combined for segmented bending. The sheet metal bender is ideal for fabricating complex structures such as electrical enclosures, instrument housings, and ventilation ducts.
- Effortless and Stable Operation: The sheet metal bender features a single balancing hammer that ensures secure clamping, reducing the force required for bending and improving overall efficiency. Pre-drilled holes in the base allow for easy mounting on a workbench or floor to prevent shifting.
- Easy Operation: The aluminum brake bender is straightforward to operate. Lift the clamping handle, position the sheet metal, and lower the handle to secure the material. Gradually raise the lever to the desired angle. Manual angle adjustment is required; note that all metal bending exhibits springback (e.g., for a 90° bend, set the angle to 92°).
Technical Specifications
| Item Model Number | W1.5×1270Z |
|---|---|
| Auxiliary Bending Method | Single Balance Hammer |
| Max. Bending Width | 50 in (1270 mm) |
| Max. Bending Thickness | 16 Ga (1.5 mm) Low Carbon Steel |
| Max. Bending Angle | 135° |
| Mounting Type | Desktop-Mounted, Manual Flanging |
| Press Plate Mechanism | Manual |
| Segments | 16 (2″ x 4pcs, 3″ x 6pcs, 4″ x 6pcs) |
| Material | Low Carbon Steel |
| Weight | 432.1 lbs (196.0 kg) |
| Frame Dimensions | 61.9 x 15.7 x 18.9 in (1571 x 400 x 480 mm) |
| Product Dimensions (with Balance Hammer) | 61.9 x 15.7 x 21.3 in (1571 x 400 x 540 mm) |
Detailed Overview
Sheet Metal Brake for Rapid Batch Bending
Bend metal like a pro with this 50-inch sheet metal brake. Ideal for workshops, the box and pan brake handles 16 gauge steel, supports multiple materials, and features modular fingers for complex bends—easy to use, stable, and built for precision bending.
The box and pan brake handles mild steel, stainless steel, aluminum, and copper with ease. Bends 16-gauge (1.5 mm) mild steel in a single pass—no need to swap between machines for different jobs.
The sheet metal bender includes 16 removable fingers in multiple sizes that can be freely arranged to avoid obstructions on the workpiece. Ideal for forming floor reinforcement channels, corrugated truck beds, bed headers, and inner fenders.
Enhanced with a balancing weight to offset the force during clamping, minimizing deformation—an upgrade over standard brakes. Bolt it down to your workbench to ensure steady, accurate bends.
Always wear goggles, non-slip gloves, and safety shoes before operating the metal bending brake. Stand to the side during bending to avoid injury from springback. For larger sheets, team up with a partner for secure handling.
Note: Great Oak specializes in sourcing high-performance industrial tools. Manufactured by VEVOR.
Verified Customer –
The unit is solidly built and performs bends exactly as advertised. Very satisfied with the quality.
Verified Customer –
Works great for light-gauge aluminum. Makes accurate, clean bends. Just what we needed.
Verified Customer –
This unit is very well made. Strong construction and solid components.
Verified Customer –
Arrived in excellent packaging. Some minor hardware was missing due to shipping damage, not the manufacturer’s fault. Fit and finish are impressive—oil fittings, accurate degree wheel, and nearly perfect alignment. Performs better than many big-name brands for the price.
Verified Customer –
Used an 8-foot brake before, but this 48″ model fits my budget. Built a stand for it and I’m very satisfied so far. Solid performance.
Verified Customer –
This is a true finger brake with a wide 24″ finger, making it ideal for sharp, clean bends. The fingers are easy to adjust and remove. Highly recommended.
Verified Customer –
With 35 years in metalwork, I got this brake for home use. It’s well-built, produces straight bends, and easily handles 16-gauge metal. Great addition to my shop.
Verified Customer –
This machine works perfectly for small stainless steel parts (26 gauge). It’s compact, easy to use, and delivers great results. We even made a custom 1.5″ tool and it works flawlessly. Very happy with this bender.
Verified Customer –
does everything that a name brand does. Nice and easy to bend sheet metal. looking forward to using it a lot more
Verified Customer –
My first venture into doing this, or any, type of sheet metal bending. After a lot of research and watching several Youtoob reviews, I ordered this Vevor brake. Took my time building a sturdy bench just for the brake. Boy, this thing is heavy!
At any rate, I just finished my first project (tube amp chassis) and was totally successful. I uses .060 aluminum, and the brake handled it easily. There’s limitations with this brake, but I just engineered my way around them. Actually, my limitations are quite probably due to my having zero previous experience with tools like this, and I’m facing an expected learning curve on the uphill road to success.
On delivery, I could see that the brake was securely packed and bolted in a wooden crate, but TBH the crate pretty much fell apart before it got here, and was taped together by the carrier. Zero damage to the tool, though. No harm, no foul.
Happy I bought it, would definitely make this same choice again.
