Description
Great Oak Curated Industrial Equipment:
Part of our industrial collection, selected for durability and performance.
Features & Details
- 4-Inch Milling Machine Rotary Table: Elevate your milling capabilities with our φ4'' / 100 mm rotary table, which is ideal for small milling machines. It is designed for precise positioning, rotation, indexing, and clamping of wood and metal workpieces for curved surface machining, elongated hole processing, and precision drilling. Widely used in automotive, mold-making, and general machinery, underscores its essential role in mechanical processing.
- φ4'' / 100 mm rotary table
- Designed for precise positioning, rotation, indexing, and clamping
- Compatible with wood and metal workpieces
- Applications: curved surface machining, elongated hole processing, precision drilling
- Used in automotive, mold-making, and general machinery industries
- Secure Small Workpieces with Ease: Our rotary table comes with a 3-jaw chuck, and the serrated jaw ensures a firm grip on even the smallest workpieces. Chuck Diameter: φ 3.1'' / 80 mm. The internal jaw can be used for internal & external clamping. External Clamping Range: 0.08''-0.9'' / 2-22 mm, Internal Clamping Range: 1.0''-2.8'' / 25-70 mm. It includes an external jaw and external clamping range of 0.9''-2.5'' / 22-63 mm. Enjoy the precise and secure machining of small components!
- High Precision at Your Fingertips: The milling machine rotary table is operated by a handwheel, complete with crystal-clear scales on both the wheel and the table for precise measurements. The handwheel scale is marked at 100, while the table itself is calibrated to 360 degrees. With a worm gear ratio of 1:36, a single rotation of the handwheel results in a 10-degree turn of the table, aligning perfectly with intuitive operation and allowing for precise control over even the slightest rotation.
- Horizontal & Vertical Installation: When mounted horizontally, the chuck top height is 4.7'' / 120 mm (±3 mm); when mounted vertically, the chuck center height is 2'' / 50 mm. This rotary table is compatible with both industrial and home-use milling machines, provided your milling machine's tool height exceeds the respective vertical or horizontal installation heights. Additionally, the table's bottom includes positioning slots for secure and easy attachment to your milling machine.
- Exceptional Durability, Built to Last: Step up your milling game with our exceptionally durable rotary table crafted from HT250 cast iron for maximum wear resistance and a high-hardness surface that resists scratches and corrosion, ensuring an extended lifespan. Even under heavy loads, high pressure, and rapid rotation, our rotary table maintains its integrity and durability. Choose our HT250 cast iron rotary table for a high-quality performance in your milling operations.
Technical Specifications
| Item Model Number | HV-4-KP |
|---|---|
| Table Diameter | 4 in / 100 mm, ±2 mm |
| Top Height for Horizontal Mounting Chuck | 4.7 in / 120 mm, ±3 mm |
| Center Height for Vertical Mounting Chuck | 2 in / 50 mm |
| Rotary Table Handwheel Scale Value | 6′ |
| Rotary Table Handwheel Scale Number | 100 |
| With or Without Vernier Scale | No |
| Worm Gear Ratio | 1 |
| Chuck Diameter | φ 3.1 in / 80 mm |
| Net Weight | 11.7 lbs / 5.3 kg ± 3% |
| Product Dimensions | 6.3 x 5.8 x 4.7 in / 160 × 148 × 120 mm |
Detailed Overview
4-Inch Rotary Table for Milling Machine
Our 4”/100 mm diameter rotary table is the perfect companion for small milling machines or specialized machinery and is designed for intricate and complex dividing cuts. Embrace the efficiency and versatility of our 4-inch rotary table and take your milling projects to the next level of accuracy.
Our rotary table comes with a 3-jaw chuck and requires additional installation! We offer two types of jaws, internal jaw and external jaw, which easily open and close with a T-shaped chuck wrench, ensuring a secure and precise grip on your workpieces.
Enjoy the precise machining with our meticulously designed milling rotary table featuring a worm gear ratio of 1:36 and a fine, clear scale. Every rotation is under your control, with a dedicated degree lock. Once you set your angle, it stays put, ensuring stability and consistency in your work.
Discover unparalleled versatility with our milling machine rotary table, ingeniously designed for both horizontal and vertical applications. The precise positioning slot on the bottom ensures the rotary table remains stable and shake-free during operation.
Our rotary table is crafted from HT250 cast iron for exceptional wear resistance and high hardness and is a staple in precision and heavy-duty machining industries. Choose our rotary table for a lasting addition to your workshop, where strength meets precision at every turn.
Note: Great Oak specializes in sourcing high-performance industrial tools. Manufactured by VEVOR.
Verified Customer –
Used it on a few projects now. Very pleased with this product for the price. The only complaints I have are very minor and minor. 1) The “On / Off” engagement labeling for the worm gear is backwards. I believe someone else mentioned this too. Does not affect function at all, just causes confusion the first time you’re trying it out. 2) If the worm gear is engaged all the way there is a very sticky spot somewhere along it. I am getting around it by only ‘mostly’ engaging it; when I do that there is no sticking but there is I believe more free play. I can make that work since I’m not doing precise enough work to need the graduations on the handle.
Verified Customer –
I bought this for a job, used it then “fixed it”. I had to make a 12″ dia. disk, then make slots in the disk.
I had the worst chatter while turning the handle and cutting. Also seemed to have tight spots. When I finished the job, I took the table apart to see if there was anything I find that would cause this, maybe some backlash or something I could fix.
The table works by turning the handle, which drives a worm gear set. The hub of the worm gear is (should have been) bolted to the table top. There are two sets of bolts for this job.
What I found was they had counterbored one of the sets too small. So the socket head cap screw would not down the bore. This in turn didn’t have enough threads engaged to hold the hub onto the table and they had all backed out or were stripped out. There is 6 of these screws and one of the six didn’t even line up and was missing. The other set of holes had a chamfer on the bottom for socket head cap screws, so the bottom of the SHCS made point contact with the chamfer. The fix was to take the right sized end mill and correct the counterbores.
To finish, I broke all the edges with a file and stoned the flat surfaces.
For the price, some “rework” should be expected. I expected I would have to remove burrs. I didn’t expect to have to fix holes. The customer for this table will likely have the skills to rework this table as it comes out of the box.
Verified Customer –
Rotary table worked as advertised! Maybe it isn’t top grade hardware, I’m not a machinist and I don’t have years of experience in machining. But the backlash isn’t crazy, table rotates smoothly, and I think it is 10 seconds accurate. There were some issues with shipping, not of this rotary table, but of a compound table (sold by the same company), but ultimately everything worked out.
Verified Customer –
Works pretty good although as I turn the table a certain way, the on/off feature go’s to off which allows the table to quit moving. This may work in some instances but for now I tightened the set screw so the lever can’t go to off. Other than that everything works fine. Easy to turn, the table locks work good and it seams to be pretty accurate. I used it to make some adopters from 3 hole wheel pattern to a larger 4 hole I’m going to use one a go-kart.
Verified Customer –
This rotary table can not be beat for the price. The fit and finish were more than acceptable right out of the box. I did have a problem with the micro dial being etched in the wrong direction. Contacted the sellers customer service and they are shipping me a replacement part. Great tool, great price and great customer service.
Verified Customer –
Very pleased, with the shipping & quality of the tool. The size is good for my Bridgeport mill. I did disassemble and clean before first use.
Verified Customer –
Works as expected, has a little backlash but have seen worse. Would purchase again if I needed to.
Verified Customer –
This small rotary table is convenient for small projects and is working well for me it is a great addition to the mill for small work items.
